Technical Specifications:
Clamping Force: 135 ton
Shot Weight (Max): 339 g
Distance Between Tie-Bars (H): 400 mm
Distance Between Tie-Bars (V): 400 mm
Screw Diameter: 50 mm
Mould Thickness (Max): 500 mm
Mould Thickness (Min): 150 mm
Opening Stroke (Max): 400 mm
Ejector Force: 5.09858106488964 ton
Ejector Stroke: 150 mm
Dry Cycle (S): 45 s
Screw L/D Ratio: 20
Screw Speed: 520 rpm
Screw Torque: 1100 N·m
Injection Volume: 353 cm³
Injection Pressure: 1464 bar
Injection Rate: 180 cm³/s
Plasticising Capacity: 38.8888888888889 g/s
Heating Zones: 3
Heating Capacity: 9 kW
Oil Tank Capacity: 245 l
Orientation:Horizontal
Other Specifications:
Machine bought in 2010 completely overhauled
Other Details:
Rebuild: 2010
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 31 Kw
