Used SUMITOMO Systec Multi 210/580-430h/200r of 2021 for sale

Bi-Injection moulding machine SUMITOMO, In MachinePoint we work so that our buyers receive a professional service and so the transaction is safe.

Data Sheet of Used SUMITOMO Systec Multi 210/580-430h/200r

Ref. : 300044037

Year: 2021


Status: For sale

Delivery time: Immediate

Technical Specifications:

Clamping Force: 210 ton

Mould Height (Max): 790 mm

Screw Diameter: 35 mm

Screw L/D Ratio: 20

Screw Diameter: 30 mm

Screw L/D Ratio: 20

Distance Between Tie-Bars (H): 580 mm

Mould Height (Max): 790 mm

Mould Height (Min): 340 mm

Daylight Between Platens (Max): 580 mm

Core Pulls:Yes

Number Of Core Pulls: 2

Other Specifications:

The machine is brand new. It has been installed, but has zero worling hours.

Polaform turntable type PF800
Turning plate diameter: 800mm Total
height: 148mm

Ejector position:
8x on X = 203,2/Y = 50,8 and X =50,8/Y=203,2 R25mm
4x on X = 0/Y = 91,2 mm and X =8¡91,2 / Y=0
automatic lubrication between turn plate and base plate

Equipped with both vertical and horizontal injection

Wittmann Battenfeld robot available. Price on request

Other Details:

Guarantee: Without guarantee

Current condition: Not running. Can be shown with material

Availability: Immediate
