Used MORELLI REX R01 of 1990 for sale

Extrusion Blow Moulding machines up to 10L MORELLI, In MachinePoint we work so that our buyers receive a professional service and so the transaction is safe.

Data Sheet of Used MORELLI REX R01

Ref. : 300044547

Year: 1990


Status: For sale

Delivery time: Immediate

Technical Specifications:

Container Size With Actual Configuration: 5 l

Number Of Heads: 1

Material Type:PE PP

Container Size (Max): 5 l

Number Of Stations: 1

Output Capacity U/H Or Kg/H:Kg/h 75

Extruder Type:Continuous

Number Of Extruders: 1

Screw Diameter: 80 mm

L/D: 25

Wall Thickness Control: YES

Other Specifications:

Mould platen sizes (mm) 270X370
Opening stroke (mm) 320
Automatic deflashing unit

New electrical panel with programmable automaton.
New pneumatics of first brands (Festo and Neumax).
Hydraulics revised and new hoses.
Adjustable head and extruder with hydraulic height adjustment.
Digital temperature controls.
All heating wiring,electrovalves,
Mould for 4 liters bottle, INCLUDED!

Availble for an extra cost:

- Leak tester
- Water chiller 50.4 kw
- Ultrasound machines Mecanosonic

Other Details:

Rebuild: 2022

Guarantee: Without guarantee

Current condition: Not running. Can be shown in dry cycle

Availability: Immediate

Voltage: 22.5 Kw
