Used KARLVILLE 300D-HS/400D-HS of 2007 for sale

Special welding machines KARLVILLE, We will be by your side all along the process of buying your machinery, from the initial assessment, accompanying you in the visits, legal and technical consultancy, and defined contracts that will protect you.

Data Sheet of Used KARLVILLE 300D-HS/400D-HS

Ref. : 300045592

Year: 2007

Brand: KARLVILLE

Status: For sale

Delivery time: Immediate

Ask for machine price »

Want to sell your machine? »

Technical Specifications:

Other Specifications:

Sleeve forming machine
Max. unwinder width : 620mm
Max unwinder diameter : 550mm
Min-max unwinder width : 60-300mm
Max rewinder diameter : 600mm
Unwinder/rewinder ID : 3" (76mm)
Machine speed : 5-300 m/min

Sealing machine 300D-HS/400D-HS
Direct injection
Adjustable forming tray
EFD Solvent tank & Accuweb EPC

Standard accessories :
YASKAWA main motor, Vector Control AC Mode 2HP, 3HP
CIRO, main motor
YASKAWA, rewinder motor : Vectro Control AC Mode 2HP, 3HP
CIRO rewinder motor
FATEK programmable control system (PLC Based)
HITECH touch screen for display functions and magnetic energy brake control operation
Magnetic energy brake 2.5Kg Unwinder
Tension sensor, unwinding and rewinding units
Drying Blower, 1/8HP, 3PH
Expander for 3" rewinder shaft
Adjustable forming base
Bearing
Static Eliminator
Standard Safety Modifications
Tool box

Included accessories :
ACCUWEB - Positioning control system (EPC) on the unwinder
Mechanical oscillation system on the rewinder
Direct injection system
BST Web width measurement system for ProSleeve

The machine was in production last month, a test run could be done, but only rewind because there is no more staff and adhesive.
