Used ENGEL Victory 500/120 Focus of 2008 for sale
2008 | Ref.: 300047777
Injection molding machine up to 250 T ENGEL, In MachinePoint we work so that our buyers receive a professional service and so the transaction is safe.
Data Sheet of Used ENGEL Victory 500/120 Focus
Ref.: 300047777
Year: 2008
Brand: ENGEL
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 120 ton
- Shot Weight (Max): 250 g
- Platen Size (H): 740 mm
- Platen Size (V): 680 mm
- Screw Diameter: 45 mm
- Daylight Between Platens (Max): 800 mm
- Opening Stroke (Max): 500 mm
- Ejector Force: 4.05847052765215 ton
- Ejector Stroke: 130 mm
- Core Pulls: Yes
- Number Of Core Pulls: 1
- Dry Cycle (S): 3 s
- Injection Pressure: 1030 bar
- Injection Rate: 162 cm³/s
- Nozzle Force (Max): 5.19 ton
- Nozzle Stroke (Max): 300 mm
- Heating Zones: 4
- Oil Tank Capacity: 300 l
Other Specifications:
Working hours 61 000 h
Other Details:
Guarantee: Without guarantee
Current condition: Disconnected. Can't be seen in running condition
Availability: Immediate
Voltage: 380 V Triphase
Frequency: 380 V Triphase
