Used UNILOY MSC97/D of 1998 for sale

1998 | Ref.: 300047910

Extrusion Blow Moulding machines up to 10L UNILOY, MachinePoint offers their clients all the services necessary to buy the machine: Transport, dismantling, and legal consultancy.

Data Sheet of Used UNILOY MSC97/D

Ref.: 300047910

Year: 1998

Brand: UNILOY

Status:

For sale

Delivery time: Immediate

Ask for machine price Want to sell your machine?

Photos

Technical Specifications:

Container Size With Actual Configuration: 5 l
Number Of Heads: 1
Material Type: PE
Number Of Stations: 2
Extruder Type: Continuous
Number Of Extruders: 1
Screw Diameter: 80 mm
L/D: 24
Wall Thickness Control: YES

Other Specifications:

Mould platen sizes (mm) 320x430
Opening stroke (mm) 390
Clamping force 10 Ton
Deflashing unit Yes
Leak tester No
Installed power 97 kw
Average consumption 40 kw

Other Details:

Guarantee: Without guarantee

Current condition: In Production

Availability: Immediate

Voltage: 460 V Triphase
Frequency: 60 Hz
Voltage: 97 Kw

MachinePoint's services:

Loading and lashing

Packaging

Dismantling

Extra products and services for extrusion blow molding machines

Moulds for Injection Stretch Blow moulding machines

Extrusion Heads for Blow Moulding extrusion machines

Refurbishing & Overhauling services

Used Machinery Appraisals

Transport of industrial machinery

Similar Products:

UNILOY UMS-100 LSD

Extrusion Blow Moulding machines up to 10L

2019

Ref: 300047503

UNILOY

More information

UNILOY HSM 10/D

Extrusion Blow Moulding machines up to 10L

2004

Ref: 300049313

UNILOY

More information

TECHNE System 10000 - T900 coex-3

Extrusion Blow Moulding machines up to 10L

2003

Ref: 300046240

TECHNE

More information

JOMAR EBM 6-D

Extrusion Blow Moulding machines up to 10L

2003

Ref: 300034633

JOMAR

More information

PLASTIBLOW PB10000S

Extrusion Blow Moulding machines up to 10L

2006

Ref: 300045274

PLASTIBLOW

More information

INGERSOLLRAND ML15

Air Compressors (Low Pressure)

2001

Ref: 300040856

INGERSOLLRAND

More information

GARDNER DENVER EAU99S

Air Compressors (Low Pressure)

2008

Ref: 300042655

GARDNER DENVER

More information

KAESER SK22

Air Compressors (Low Pressure)

2018

Ref: 300046146

KAESER

More information

Machines sold in the past:

UNILOY UMS220-D EZ year 2010

Max. mold width 700 mm Max. mold height 470 mm Half mold thickness 180 mm Max. mold weight (each carriage) 500 kg Platens dimensions (w x h) mm 520 x 450 Max. Daylight between platens 720 mm Clamp force kN 200 Horizontal shuttle stroke mm 710 Average consumption 80 kW HMI touch screen panel installed new in May 2022 Leak tester Deflashing unit Gravimetric dosing unit Morreto Shini Low Speed Granulator Available: March 2025

UNILOY UMA 17.70.2 year 1997

clamping force 245 KN stroke 220 x 2 Daylight min-max 310-750 mm Closing speed 350 mm/sec Platen dimensions 540x810 mm Rpm 0-85 DC motor power 50,2 kW NOTE: available a 2nd machine year 1996 (price and pictures on request)

UNILOY UMA-60 10 liter head year 1998

Accumulator head machine Capacity 10 kg (PP)

UNILOY UMA 30-80-6L year 2002

Clamping force 300 kN Clamping speed 900 mm/sec Mould clamp dimensions 600 x 800 mm Daylight 1100 mm Min mould thickness 205x2 mm PLC Siemens S7 Available January 2025 Screw and Cylinder renewed

UNILOY MSC/S year 1990

Leak tester
