Used BUHMANN C300 / PF800 of 2016 for sale
Packing machine for glass bottles BUHMANN, You can contact our team and analyze your needs so we can offer you the best possible solution depending on your budget.
Data Sheet of Used BUHMANN C300 / PF800
Ref.: 300048584
Year: 2016
Brand: BUHMANN
Ask for machine price Want to sell your machine?
Technical Specifications:
- Output: 13200 U/h
Other Specifications:
Fully automatic packaging system for jars with upstream carton erecting unit (wrap-around trays)
Buhmann pac solutions System GmbH
Construction year 2016
In addition to the packaging of unmixed cartons, the automatic mixing of
offline products (feed via separate feed belt for mixed cartons).
Carton erector: Type C300
Packing unit: Type PF800
Working hours 5.000
Product infeed online: max. 280 jars/min Capacity restriction format 3: max. 220 jars/min
Mixing type A: max. 140 jars/min or 11.5 cartons/min
Mixing type B: max. 140 jars/min or 11.5 cartons/min Total output (online, A, B): max. 350 jars/min or 30 cartons/min Case erector C Covering machine: 23.5 cartons/min required
Changeover time: complete format changeover approx. 15 min
The output depends on the packaging materials and packaging aids to be processed
Prozess Description:
- Acceptance of the products (online track type A) and transportation to the individual packaging modules (processing of the jars using individual handles)
- Separating the flat cardboard blanks from a magazine
- Gluing, folding and gluing the carton
- Transporting the cartons to the individual packaging modules
- Manual loading of filled trays at 2 stations (type B and C) incl. buffer section for trays
- Unloading the manually fed trays
- Transport of the products (types B and C) to the individual packaging modules
- Unloaded trays are automatically fed to the carton line
- The jars are inserted into the cartons continuously, each jar is inserted individually
- Packaging modules work independently of each other, i.e. if one unit fails, the
line can continue to operate
5 jar sizes available : 220 g - 340 g (2 different glass formats) - 470 g - 650 g
Actually filling moustard but can pack all kind of jars
Plant in very good condition
Unit(s) were carried out annually with Buhmann C Yaskawa.
Professionally dismantled with electrical documentation (by Scholpp) and stored in a dry/protected location.
Other Details:
Guarantee: Without guarantee
Current condition: Dismantled. Can't be seen in running condition
Clasification:
Final Products: Mustard
