Used BENCO PACK Asepack/8-D P336 of 2005 for sale

Cup Form Fill and Seal Machine Bencopack Packline/8 composed by: Machine Standards for PACKLINE/8 Machine in hygienic version with UV lamps Set of customized parts for cups of 125 ml Filling unit model DOSY/190 In-mould labeling device (IML) Packaging line model: PACKLINE/8 Mechanical working speed: 30 cycles/min. Nominal hourly output: Up to 14.400 cups Number of thermoformed cups/cycle: 8 Forming area: 4x2 Cup capacity: 125 ml (basic cup) Cup dimensions: 63x63 mm Type of cut: without intermediate scraps Cutting configuration: Multipacks of 2 and 4 cups Materials usable for the cup bottom: PS Materials usable for the cup lid: AL+PET, Paper/PET Forming, sealing and cutting stations: driven by servo-motors Tunnel for the protection of the thermoforming and filling zone by means of ultra-filtered air Automation and control system by PLC SIEMENS FILLING UNIT model DOSY/190 Volumetric filling unit suitable semi-liquid and creamy products, composed of: · Filling pumps driven by servo motor. · Filling nozzles suitable for the products to be filled, equipped with anti-drop device. · Product and cleaning solution interception valves. · Hermetically sealed manifolds for the conveyance and recovery of the cleaning solutions, allowing CIP cleaning by automatic insertion of the manifold onto the filling nozzles Filling capacity: 50 ÷ 190 ml Solid particles: Max 5 mm cross section Filling accuracy: +/- 1% (min 1 g) for homogeneous products Filling volume adjustment: through the machine control panel Filling performance: according to machine cycles and depending on products and products’ characteristics (viscosity, homogeneity, filling temperature, solid particles). IN-MOULD CUP LABELLING - IML The supply includes: · Paper roll un-winder consisting of a device that supports the paper label roll · Rotary cutting group consisting of a motorized group of rotary blades that cut the paper film in longitudinal stripes · Stripe transport from the rotary knife to the counter-mould · Stripe feeding device consisting of couples of motorized rolls that insert the stripes into the counter-mould · Label cutting device consisting of a group of scissor-blades that cut the labels from the stripes in the desired length by means of reference spots printed on the paper film · Counter-mould consisting of a unit that received the labels from the stripe feeding device and inserts them into the tilting forming mould · Tilting mould that rotates by 90° after cup forming to release the formed cups and meet the counter-mould to receive the cut labels Feeding of labels: Automatic Cycles/min. and hourly output: According to the packaging line Max. diameter of paper roll: 500 mm Construction: In stainless steel and light alloy Printing on the paper: Centered by means of a photoelectric eye Machine in excellent condition, like new!!! Sold with 12 months guarantee
