Used HERBOLD SMS 80-100 of 2018 for sale

Without electric cabinet 1 used Herbold friction washer FA 3000 Rotor length: (mm) 3000 Paddel rotor diameter: (mm) 500 Rotor speed: (rpm) 1000 Standard screen hole size: (mm) 2,5 Max. screen hole size: (mm) 3 3 Standard drive: (kW) 18,5 Drives: (kW) 11-22 Weight: (kg) 1300 Throughput approx. : (t/h) * HDPE 3,5 LDPE 2 1 used Herbold separation container (3000x1000) 1 used discharge screw 1 used Herbold dryer T 1015 Diameter screen drum 900 mm Working length 1450 mm Drive 30 - 90 kW Dimensions: Length 2600 mm Width 2400 mm Height 2200 mm Height with opened cover 3700 mm Screen hole size (standard) 2,5 mm Throughput up to (t/h) Rigid plastics 2,0 Film - 0,8

Heavy duty granulator with a hinged device with electric winding winch. Open rotor, optionally as open 3- or 7-blade rotor. A guillotine rotor with 3 knives is currently installed, which is a special rotor for pelletizing unvulcanised rubber blocks, for example. It is also ideal for large portions of films and fibers. It is also possible to install a standard 7-knife rotor (at no extra cost), if is more suitable for the material. Stator knives: 2 Rotor knives: 3x2 Rotor width: approx. 1000 mm Infeed opening: approx. 700 x 1000 mm

The complete line includes a Herbold machine with control cabinet and hydraulic pump for the press that presses the material onto the rollers. A cream coloured belt feeder/magnet above the belt and a big-bag holder. The capacity of the machine varies depending on the product to be shredded / whether e.g. pallets - wood or plastic The machine is connected and can be tested at any time. Additionally a one REIßMESSERWELLE Z1 B68 T30 G ZW 1100 knife is available 4.500,00 excl. VAT

HV 70 Plastcompactor for the agglomeration of film and fibres. Throughput according to the material between 500- 1000 kg/h Conveyor belt Centre distance approx. 6000 mm Belt width approx. 1000 mm Power 2.2 kW With metal-free zone for mounting an inductive metal detector. Herbold Granulator Typ SMS 45/100-H5-3 90 kW three-phase motor Material transport to the storage silo Herbold Plastcompactor, type HV 70/250 Consisting of: 1 Storage silo feeding screw With agitator approx. 5.5 kW Theoretical filling volume: approx. 1.2 m³ material: mild steel Feed screw drive: approx. 11 kW 1 HERBOLD Plastcompactor, type HV 70/250 Tools: Disc diameter: 700 mm Housing: In welded steel design Bearing of rotating disc: Roller bearings in cast flange bearing housing, bearing sealing with rotary shaft seals Drive: V-belt with protection Three-phase motor: P = 250 kW Central blower: Transport fan (central blower) Herbold granulator type SML45/100-S4 2 Drive motor: 37 kW three-phase motor Intensive cooling: Consisting of 2 nozzles for the introduction of a fine spray mist to cool the grinding chamber. Blower with fines separation and fines return SZS II 630/200 Classifier unit for separating the fines from the agglomerate and returning the fines to the silo, 1 Screening machine: For screening the undersize particles (fines) Screen tension 1000 micron Diameter 1200 mm Drive approx. 2.2 kW Material conveyor type MFT with big bag station and automatic switchover to the on-site silo Material conveyor blower with drive motor approx. 11.00 kW, connecting pipework, cyclone separator with frame, double discharge spout for big bag filling, automatic switchover from big bag 1 to big bag 2 (and back) Automatic exhaust air filter (without ATEX devices and with preparation for retrofitting) 1 Electrical control unit 1 Industrial compressor with pressure vessel. P= 3.5kW Electrical connection to be provided on site 630 kVA

Wet size reduction of pre washed, post consumer, pressed PET bottles Material type: PET Screen size: 12 mm Input humidity: dry Output : 2500 to 3000 kg/h with knives and screens in good condition and knives properly gapped Storage hopper with forced feeding Bunker infeed height: approx. 2210 mm Hopper infeed cross section: approx. 1800 x 2000 mm Drive screw(s): 3 kW / screw With 3 horizontally mounted feeding screws. (mild steel) Material will be fed load-controlled into the cutting chamber by frequency converters The entire unit is mounted on a movable frame. Rotor diameter: approx. 600 mm Rotor length: approx. 1488 mm Number of rotor knives: 7 x 2 Number of stator knives: 2 x 2 ran only approx. 2000 hours
