Used AMUT 60/28D of 1980 for sale

TWIN SCREW EXTRUDER AMUT BA 92 YEAR 1997 COMPLETELY OVERHAULED (NEW SCREWS+CYLINDER+ CONVEYOR. COMPLETE OVERHAUL OF GEARBOX + GEAR GROUP. ALL WORK DONE AT AMUT) DC motor 59,5 kW

Single screw extrusion line for RIGID PVC including: - 1x single screw extruder AMUT 60 - Calibration table AMUT 5 meters - Roll puller belt contact 30 cm - Circular saw Cutting Height 100 mm

Twin screw extruder AMUT Year of construction 1996 for PVC profiles Manual available Screw diameter 72 mm Throughput: 180/h Application: Swimming pool 3-chamber hollow profile Haul off & Saw Brand: Elkuma 404/03 Year: 1975 Volt 380 kW 2.5 Amp 17 Hz 50 Tilting table. 8 meters long, can be extended to 12 meters

Motor AC 41 kW Working hours 44.709 (screws were replaced in 2015 with 20.000 hours)

Coextrusion line for the production of three layer polymer sheets The co-extrusion block can give the following structures: A-B-A; A-B; B-A Extruder Amut EA75/35D, year 2012 L/D 1:35 It provides layer B, with the following capacities: HIPS 350 kg/h, ABS 300 kg/h, TPU 70 kg/h AC motor, 108 kW 22 to 220 rpm 7 zones for tempering: 6 zones with a total heating power of 38 kW with air cooling, one zone is cooled by water + SELLA unit for tempering the entrance zone TEMIS/AP75 40-120oC 3.5-5 bar, water pressure for cooling. Vacuum pump 2.2 kW type D75/P Device for automatic screen change BOL/70-90 with hydraulic pump 1.5 kW 4 lit/min Melt pump GP-56/56 with a total power of 10 kW Static mixer SMP/60/S Coextruder Amut EA 48/33D, year 2012 L/D 1:33 It provides layer A with the following capacities: PMMA and ABS 40 kg/h, CrPS, HIPS 50 kg/h and TPU and polyolefins 30 kg/h AC motor, 31.5 kW 10 – 220 rpm 5 tempering zones with a total power of 11 kW with air cooling Melt pump GP 28/28 with a total power of 3.5 kW Static mixer SMP-X/30/S PIOVAN dosing system; year 2012 1.1 Model MDW 400/40; 4 components - up to 6 for the main extruder 1.2 MDW 30/30; 3 components – up to 4 for coextruder PLC Siemens S7 Calander Reifenhauser with 3rolls, year 1989 Diameter of rolls: 400 mm Width of rolls: 1800 mm KELVIPLAST roller tempering unit; year 1992 Trimming unit Guillotine JWEEL 0.2-8 mm x 2000 mm Corona CASON TLB 1500 mm generator model GET 12.5 DK3; year 2012
