Used BATTENFELD Macropower 900/8800 of 2017 for sale
2017 | Ref.: 300049460
Injection molding machine from 500 T up to 1000 T BATTENFELD, MachinePoint offers their clients all the services necessary to buy the machine: Transport, dismantling, and legal consultancy.
Data Sheet of Used BATTENFELD Macropower 900/8800
Ref.: 300049460
Year: 2017
Brand: BATTENFELD
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 900 ton
- Shot Weight (Max): 4136 g
- Distance Between Tie-Bars (H): 1200 mm
- Distance Between Tie-Bars (V): 1000 mm
- Platen Size (H): 1720 mm
- Platen Size (V): 1550 mm
- Screw Diameter: 105 mm
- Tie-Bar Diameter: 175 mm
- Mould Height (Max): 1000 mm
- Mould Height (Min): 500 mm
- Daylight Between Platens (Max): 21000 mm
- Clamping Speed: 800 mm/s
- Opening Stroke (Max): 1600 mm
- Ejector Force: 300 ton
- Ejector Stroke: 300 mm
- Core Pulls: Yes
- Number Of Core Pulls: 2
- Dry Cycle (S): 3.6 s
- Injection Volume: 4545 cm³
- Injection Pressure: 2100 bar
- Injection Rate: 725 cm³/s
- Nozzle Force (Max): 14.5 ton
- Nozzle Stroke (Max): 950 mm
- Plasticising Capacity: 151 g/s
- Heating Zones: 7
- Heating Capacity: 53.9 kW
- Oil Tank Capacity: 1100 l
- Orientation: Horizontal
Other Specifications:
Hours in Production at 22/10/2025 : 42 500 hrs
Other Details:
Guarantee: Without guarantee
Current condition: In Production
Availability: Immediate
Voltage: 400 V Triphase
Frequency: 50 Hz
Voltage: 155 Kw
