Used OMSO DM 385/6 BOX of 2000 for sale
Cup printing machines OMSO, The team at MachinePoint is constantly looking for the best offer of machinery all over the world in order to offer our clients attractive and quality machinery.
Data Sheet of Used OMSO DM 385/6 BOX
Ref.: 300049526
Year: 2000
Brand: OMSO
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Number Of Colours: 6
- Cup Height (Max): 130 mm
- Cup Height (Min): 25 mm
- Cup Type: Square
Other Specifications:
Working hours: approx: 31.950
Number of inking units: 6
Number of bottom printing stations: 2
Number of bottom printing inking units: 2
Printing inks (max.) 6
Mandrel rotary stations 6
Diameter of cliché roller 177mm
Diameter of central roller 708mm
Printing sectors on the central roller 2 or 4
Max. printing length (6 mandrels, 4 printing sectors) 400mm
Max. printing length (3 mandrels, 2 printing sectors) 480mm
Max. printing length 125mm
Printing properties of the bottom pressure module
Printing inks (max.) 2
Diameter of cliché roller 120mm
Diameter of central roller 240mm
Roller diameter of counter-pressure die 480,365mm
Punch on central roller 2
Punch on counter-pressure punch roller 4
Max. printing length 120mm
Max. printing width 120mm
Application range (cup dimensions)
Max. cup length at rim 180mm
Max. cup width at rim 135mm
Min. Angle Radius 10 mm
Cup taper 12º
Max. hourly production (depending on cup shape, dimensions, and consistency) 9000 Pieces
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 18 Kw
