Used GALLUS EMS 510 of 2008 for sale

8 colours with UV drying Auto splice unwinder Corona Two die cutting units Lamination unit ABG glueless turret Turret rewinder Web camera control Anilox: 1200/1,5 1200/1,42 1140/1,4 1140/1,4 1140/1,4 1000/1,88 1000/2,06 850/2,5 760/2,44 711/2,8 670/2,8 610/3,4 610/3,13 570/3,6 560/3,4 525/3,4 457/3,5 430/3,5 430/3,9 400/4,4 375/4,2 375/4,2 355/4,99 355/5,2 355/5,2 335/5,9 260/6,7 254/7,66 180/12 Magnetic Cylinders: 63 pcs Printing Cylinders: 339 pcs

Max. rewinder diameter: 800 mm - double shaft. Max material width: 415mm UVI lamps:5, GEW-Nuva Water-cooled roller system + chiller Double tension control Video: BST (it lacks a proximity detector to work). 2 die cutting stations, one with gap master Chiller included. PLATE CYLINDERS : Z-80,82,85,87,90,94,96,99,100,101,104,108,112,116,117,124,128,130,132,134,142,144,148, & 195 Of each there are 5 units. ANILOX: L/CM - CM3/M2 - UNIT 420 2 2 420 3 3 240 3,1 3 420 3,6 2 280 4 1 300 5 1 350 6 2 280 8 1 120 8,5 1 120 9 1 140 13 1 100 15 1 Does not include magnetic cylinders.

Unwinding Splice table Web guide Infeed unit Spindle 3” 8 flexo printing units, set for quick unit change 8 UV curing IST with water cooled chill roller 8 pneumatic doctor blades Die cut station for 2 die cuts with 1 die cut unit, 2nd position empty 1 drive unit standard 1 label counter 1 mech matrix removal unit spindle 3” 1 output section ( pull station ) 1 rewinding unit 1 pneumatic winding spindle 3” 1 tension roller 1 web break and 1 matrix break detector Razor knifes Automatic register control (included die-cut ) Corona

Maximum material width 430mm flexo sections - 7 screen-printing sections - 2 hot stamping with fractional rollers- 1 cold foil- 1 lamination - 1 Arcotec corona IST UV lamps water cooled cylinder system Tek Nek web cleaning - both sides single unwinder double rewinder Stamping stations - 3 Inspection camera Sensotec strapping control system printing on materials from 30 to 250mic, including shrink sleeve film full original technical documentation 12 ink trays Large set of cylinders, magnetic and anilox rollers Aniloxes: 23 pcs. Cylinders: 17 sets of 7pc each. 1 set of 4pc. (incomplete) Magnetic cylinders: 18pc. Screen printing gears: 24pc. Machine in continuous use. Available from April 2025. The EyeC camera shown in the video is not included.

Mechanical machine speed max. 150 m/min. Web width max. 282 mm Printing : Printing width for flexographic printing max. 280 mm Format length for flexographic printing max. 457.2 mm Format length for flexographic printing min. 203.2 mm Printing width for rotary screen printing max. 270 mm Printing width for rotary screen printing min. 130 mm Format length for rotary screen printing max. 533.4 mm Format length for rotary screen printing min. 269.9 mm Printing width for hot foil embossing 280 mm with web width max. 282 mm Format length for hot foil embossing max. 552 mm Format length for hot foil embossing min. 280 mm Format length increment 3.175 mm Number of print operations max. 12 Drying : UV Hot-air drying Flatbed processing : Processing width max. 280 mm Format length max. 304.8 mm Format length min. 139.7 mm Format length increment 1.587 mm Rotary processing : Processing width max. 280 mm Format length max. 457.2 mm Format length min. 203.2 mm Format length increment 3.175 mm Number of processing operations max. 5 Substrates : Self-adhesive materials standard Paper from approx. 60 g/m2 Others : Web guide Corona treater Vetaphone Anilox cylinders type and quantity : 26 full set List of Plate cylinders, sleeves or cassette (for offset) : Cylinder 73T to 135T Video system Manual register 1 magnetic die cutting Cold Foil Delam / relam section No web cleaner
