Used CERUTTI R960/1 of 2005 for sale

Refurbished in 2015 by Pelican (whole electronic cabinet - Siemens and basic mechanical part overhauled) Materials : PET, BOPP, PAPER Auto splicing 2 (unwinder side not working) Air shaft 3" & 6" 10 Cylinder shafts Ink cooling system 5 not installed Static observation system WEB camera BST make Quadtech-2600 ARC at all unit 2 Stroboscopes In feed and out feed CO2 stystem at all unit 72 rubber rolls

PE, PP, Cellophane, PS, Paper, Board, Cardboard, Al, Bare Al (see picture with tension table) Last two stations are reversing Hot oil heat (thermal heater not included) Rotogravure press consisting of: 1 x PB710 unwinder 10 x ES960-2 printing units 1x RB710 rewinder maximum width of the web 1020 mm minimum width of the web > 510 mm web tension range 4 ÷ 50 dan Web guiding system: Fife Polaris DP-20 Video system : AVT (new) Viscosimeters : Fasnacht + Co WIN FKR Corona treatment comprises: Corona generator, High volt Transformer, Corona station and suction. All spare parts for this press will go with it 16x Ink pans, cylinder trolleys, 12x ink pumps, Co2 system with bottles List of cylinders on request and at additional Price

Machine Cerutti 28R, 8 colours, completely renovated in 2007 : all electronics, tension control IN and OUT on unwinder, rewinder, infeed, central motor, web guide (Gama) and corona treatment. Unwinder double Ø800 Rewinder double Ø600 Material passage 960mm, printing width 920-940mm Printing repeat 350-900mm All stations are double (1500+1500mm) (length of drying area) Antistatic system GFK viscosity AVT inspection system Register control system Bobst Registron S4100 8 gas burners 14 electrical pumps Filters for the inks

9 trolleys Automatic winder and rewinder Webguide BST Web cleanner Not included Dryers set up First six sections – single dryer, Sections 7 and 8 – double dryers. Turning bars installed after section #6, can be used after 6th or 7th section) Corona treater AFS ESA manufacturer type ENULEC ESA1000 L\C. (Available new unused Enulech charging system) CO2 system No existing system, only nozles installed Viscosity control Fastnacht - (Available new unused Fastnacht VC system) No LEL system Pre register system Manual Register system Eltromat Camera system AVT, 100% inspection AVT Drive systems ALLEN Bradley Motion & Printing units Chiller Industrial Frigo. GR 14V 607Z -C (45A 380V). Open loop. Cooling water cylinder On each section. Ink pump type 3 phase motor direct controls Total printing cylinders 433 List of included cylinders 1170 mm width (print step in mm): 500x1 630x10 520x8 630x40 540x7 633x6 550x3 640x8 560x8 650x41 562x8 660x13 570x36 680x21 580x35 690x10 582x15 725x7 600x26 780x5 620x8 812x16 625x63 List of included cylinders 1370 mm width (print step in mm): 500x7 647x6 650x16 690x8 746x1

Materials: Paper 50-100 g / m2 BOPP 18-40 microns PET 12-20 mm OPA 12-20 microns PP 12-50 microns Minimum web width - 700 mm The maximum web width - 1220 mm Maximum roll diameter: 1000 mm The maximum roll weight: 1400 kg. The range of web tension: 4 - 40 daN Full rotation of the cylinder with a maximum diameter of the roll. Rewinder 2 +2 expandable cone bushing with an inner diameter of 76 to 152 mm. Winder two expandable cone bushing with an inner diameter of 152 mm. Gluing of the web during the movement in two directions Printing sections of type ES 960 A drying chamber model B0 Max. drying length (m): 2.7 Max. the air temperature at the nozzles (° C): 130 Number of nozzles for supplying air: 18 Max. velocity of air coming from the nozzles (m / s): 35 Max. air volume (m3 / h): 7700 In sections 9 and 10 of the drying chamber model M0 Max. the length of the dryer (m): 5.7 Max. the temperature of the nozzles (° C): 140 Number of nozzles for supplying air: 24 Max. velocity of air coming from the nozzles (m / s): 45 Max. air volume (m3 / h): 10,000 The circuit is designed according to the requirements of ventilation LEL 1 bay leaf before reversing sections 9 and 10 Web inspection (two-sided with the camcorder firm AVT) The equipment is equipped with a corona treatment. Web Guide eltromat 20 trollyes for cylinders Steam drying system
