Used NEGRI BOSSI VECTOR 7000 H 6500 of 2009 for sale
2009 | Ref.: 300050238
Injection molding machine from 500 T up to 1000 T NEGRI BOSSI, The team at MachinePoint will accompany you through the whole process of buying the machine.
Data Sheet of Used NEGRI BOSSI VECTOR 7000 H 6500
Ref.: 300050238
Year: 2009
Brand: NEGRI BOSSI
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 700 ton
- Shot Weight (Max): 4320 g
- Distance Between Tie-Bars (H): 900 mm
- Distance Between Tie-Bars (V): 1000 mm
- Platen Size (H): 1348 mm
- Platen Size (V): 1410 mm
- Screw Diameter: 110 mm
- Mould Thickness (Max): 1000 mm
- Mould Thickness (Min): 400 mm
- Opening Stroke (Max): 1000 mm
- Ejector Stroke: 358 mm
- Core Pulls: Yes
- Number Of Core Pulls: 4
- Screw Speed: 168 rpm
- Screw Torque: 8250 N·m
- Injection Volume: 4758 cm³
- Injection Pressure: 1480 bar
- Nozzle Force (Max): 12 ton
- Plasticising Capacity: 140 g/s
Other Specifications:
Hours worked : 69.500
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 400 V Triphase
Frequency: 50 Hz
Voltage: 248 Kw
