Used NEGRI BOSSI VECTOR 8000H 8400 of 2010 for sale
2010 | Ref.: 300050242
Injection molding machine from 500 T up to 1000 T NEGRI BOSSI, We will be by your side all along the process of buying your machinery, from the initial assessment, accompanying you in the visits, legal and technical consultancy, and defined contracts that will protect you.
Data Sheet of Used NEGRI BOSSI VECTOR 8000H 8400
Ref.: 300050242
Year: 2010
Brand: NEGRI BOSSI
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 800 ton
- Shot Weight (Max): 4700 g
- Distance Between Tie-Bars (H): 950 mm
- Distance Between Tie-Bars (V): 1100 mm
- Platen Size (H): 1400 mm
- Platen Size (V): 1550 mm
- Screw Diameter: 110 mm
- Control Type: Electronic
- Mould Thickness (Max): 1100 mm
- Mould Thickness (Min): 400 mm
- Opening Stroke (Max): 1080 mm
- Ejector Stroke: 350 mm
- Core Pulls: Yes
- Number Of Core Pulls: 4
- Injection Volume: 5160 cm³
- Injection Pressure: 1620 bar
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
