Used WELLTEC TTI-380PVC SE of 2010 for sale
2010 | Ref.: 300050244
Injection molding machine from 250 T up to 500 T WELLTEC, You can contact our team and analyze your needs so we can offer you the best possible solution depending on your budget.
Data Sheet of Used WELLTEC TTI-380PVC SE
Ref.: 300050244
Year: 2010
Brand: WELLTEC
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 380 ton
- Shot Weight (Max): 1484 g
- Distance Between Tie-Bars (H): 740 mm
- Distance Between Tie-Bars (V): 740 mm
- Platen Size (H): 510 mm
- Platen Size (V): 510 mm
- Screw Diameter: 80 mm
- Mould Thickness (Max): 740 mm
- Mould Thickness (Min): 250 mm
- Daylight Between Platens (Max): 1450 mm
- Opening Stroke (Max): 710 mm
- Ejector Force: 10.8 ton
- Ejector Stroke: 200 mm
- Screw L/D Ratio: 17,6
- Screw Speed: 130 rpm
- Injection Volume: 1649 cm³
- Injection Pressure: 1380 bar
- Injection Rate: 462 cm³/s
- Nozzle Stroke (Max): 328 mm
- Heating Zones: 6
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 380 V Triphase
Frequency: 60 Hz
