Minimum forming area: 241mm x 190mm (9.5“ x 7.5“) minimum
Sheet Width : 533mm (21“) maximum - 292mm (11.5“) minimum
Thickness range: 0.25mm - 1.50mm (0.010“- 0.060“)
Knife Length :
3330mm (131“) for APET
5000mm (197“) for other thermoform. materials
Material Roll Diameter :1000mm (39“) maximum
Dry Cycles per Minute : 50 maximum
Moulds for thermoforming machine GN 1914 DM
1. Cake tin for 15 persons
Materials: Dome: OPS glass 600 microns - Base: PET black 425 microns
Dimensions:
Diameter 235 mm
Height 110 mm
Unit weight 65 g.
2: Black PP Hot and Cold Food Tray with PET Dome Lid
Materials: Tray: Recyclable Black Polypropylene* ; use up to 75°C. Lid: PET Recyclable* ; use up to 65°C.
INTERNAL DIMENSIONS: the measurements to be given refer to useful dimensions
Tray:
L x W Tray: 23,5 X 18 cm
L x W Tray: 22 X 16,3 cm
Height: 2,8 cm
Capacity: 900 cc
Weight: 24,4 gr
Lid:
L x W Lid: 19 X 12 cm
L x W Lid: 23,3 X 17,7 cm
Height: 2,2 cm
Capacity: 575 cc
Weight: Weight: 21,6 gr
3. Food container suitable for microwave oven heating
Material: Black PP
Dome: 100% recyclable PET with anti-fog treatment (Anti-fog).
Dimensions:
Cavity 1 Cavity 2
Length 117 mm 145 mm
Centre width 100 mm 85 mm
Height 50 mm 50 mm
Capacity: 1,100 cc 550 cc
Unit weight: 50 g
4.- Container for cold ready meals and salads
Material: PET 70% recycled / 30% virgin (100% recyclable material)
Dimensions: Length 225 mm- Centre width 175 mm - Side width 100 mm - Height 55 mm
Capacity: 2.500 cc
Weight: 53 gr
5.- 6 oz. pastry pot with lid
Material: Bi-Oriented Glass Polystyrene (BOPS)
Dimensions:
Diameter:
Outside with lid 9.4 cm
Inner rim 7,8 cm
Base 4,8 cmHeight 6,6 cm
Capacity: With lid: 200 cc (7 oz) / Without lid: 170 cc (6 oz)
Unit weight: 7 gr
6.- Pot / Hinged lidMaterial : 500 micron translucent polypropylene
Dimensions : Length 11.4 cm (Inside). Width 7,2 cm - Height 7 cmCapacity: 650 cc
Weight: 13,2 gr
Dimensions: Length 11,4 cm (Inside): Length 11,4 cm (Inside) Width 7,2 cm Height 3 cm
Capacity: 280 ccWeight: 13,2 gr
7. 2 cavity heat sealable food tray, suitable for microwave oven use.
Material: Heat-sealable polypropylene (PP/PE)
Dimensions:
Cavity 1 Cavity 2
Length 145 mm 145 mm
Width 110 mm 80 mm
Height 35 mm 35 mm
Capacity: 420 cc 280 cc
Unit weight: 26 gr
8. Food Tray - Heat sealable, with gas barrier, suitable for use in microwave ovens.
Material : Polypropylene heat sealable barrier (PP/PE, 760/40 mic)
(Material approved for food contact in compliance with EU 10/2011 and CFR 21 USA-FDA)
Dimensions. Length 19.8 cm - Width 14.7 cm - Height 3.5 cm.
Capacity: 1.000 cc
Unit weight: 26 gr
9. Container with Lid for Food
Material: Container: Polystyrene glass 650 microns
Lid: Polystyrene glass 300 microns with anti-fogging
Dimensions: Length 19 cm: Length 19 cm. - Width 14 cm - Height 8 cm.
Capacity: 2000 cc
Unit weight: 41 gr
