Used ITALTECH KS1600 of 2009 for sale
2009 | Ref.: 300050328
Injection molding machine from 1000 T ITALTECH, The team at MachinePoint will accompany you through the whole process of buying the machine.
Data Sheet of Used ITALTECH KS1600
Ref.: 300050328
Year: 2009
Brand: ITALTECH
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 1570 ton
- Shot Weight (Max): 8310 g
- Distance Between Tie-Bars (H): 1800 mm
- Distance Between Tie-Bars (V): 1400 mm
- Platen Size (H): 2520 mm
- Platen Size (V): 2120 mm
- Screw Diameter: 140 mm
- Tie-Bar Diameter: 280 mm
- Mould Thickness (Max): 1600 mm
- Mould Thickness (Min): 600 mm
- Daylight Between Platens (Max): 3400 mm
- Opening Stroke (Max): 2800 mm
- Ejector Force: 22.6 ton
- Ejector Stroke: 300 mm
- Dry Cycle (S): 13 s
- Screw L/D Ratio: 22
- Screw Speed: 90 rpm
- Screw Torque: 12000 N·m
- Injection Volume: 11545 cm³
- Injection Pressure: 1735 bar
- Injection Rate: 1000 cm³/s
- Plasticising Capacity: 130 g/s
- Heating Zones: 7
- Heating Capacity: 105 kW
- Orientation: Horizontal
Other Specifications:
Italtech press, model KS 1600
Year: 2009
Two-stage clamping unit
Electric die with inverter
Gefran control system
Dal Maschio robot included
Machine tested
12-month warranty on spare parts, covering the machine only
Machine installation included within Europe. Please enquire for prices outside Europe.
Loading onto lorry/container included
Operating hours: approx. 40,000 (June 2026)
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 406 Kw
