Used WINDMÖLLER & HÖLSCHER GARANT TRIUMPH 5QT + LINAFLEX NL of 2021 for sale

Automatic double winder and unwinder Electrostatic discharge Eltex Web break sensors Viscosity control Electro Static Assist (ESA) Eltex model ES53 Register Control System BST Regi_star20 CO2 Fire Suppression System Inspection Camera 100% Inspection BST, year 2021 , Eltex Corona Treater AFS 2 sides Pre-Register Model BST Regi_star20

Head Diameter: 630 mm Number of Extruders: 3 Screw Diameter: 70 / 90 / 70 mm Die Gap: 2.4 mm Film Width: 1,500 – 2,600 mm Film Thickness: 15 – 250 µm Corona Treatment on Both Sides Profile Control Inner Air Circulation Carbon Brushes De-ionizing Equipment Core diameter 76 and 150mm Maximum Reel Diameter: 1,000 mm

Head Diameter: 500 mm Number of Extruders: 3 Screw Diameter: 70 / 90 / 70 mm Die Gap: 2.4 mm Film Dimensions Film Width: 1,400 – 2,200 mm Film Thickness: 15 – 250 µm Corona Treatment on Both Sides Profile Control Inner Air Circulation Gel Detection De-ionizing Equipment Core diameter 76 mm and 150 mm Maximum Reel Diameter: 1,000 mm

Head Diameter: 500 mm Screw Diameter: 70 / 90 / 70 mm Die Gap: 2.25 mm Film Dimensions Film Width: 1,415 – 2,200 mm Film Thickness: 20 – 250 µm Corona Treatment on both sides Profile Control Hole Detection Inner Air Circulation Gel Detection: Yes De-ionizing Equipment Core diameter 76 and 150mm Maximum Reel Diameter: 1,200 mm

Type of inks: Solvent-based Machine direction: Left Hand Printing Speed: 400 m/min Type of materials: PE OPP CPP PA PET paper Min web width: 660mm Thickness: min: 12 micron max 200 micron Automatic turret unwinder/rewinder Max. reel diameter: 1000 mm Number and sizes airshafts for winders if shafted:2 pcs – diameter: 150mm Inner Core Ø Unwind/Rewind 76 mm Inner Core Ø Unwind/Rewind 152 mm Web guide Automatic Register System EasyReg S (Labels) Automatic Impression Setting : EasySet S/EasySet HD Video camera AVT 100% inspection system Argus2 2013 Corona treater AFS Single Side 6KW Web Cleaner ACE Viscosity control Inkspec – 3 solvents units Accesories included: Plate Mounter AV Flexologic, model dd plus overlay High-pressure CO2 system Spare parts Aniloxes: 34 pcs Type volume (cm3) GTT 4,2 GTT 4,2 GTT 4,4 GTT 4,2 GTT 4,3 GTT 4,5 GTT 4,4 GTT 4,1 GTT 4,2 GTT 4,2 340 5,5 340 5,3 340 5,4 340 5,6 340 5,5 300 7,4 290 7,2 255 7,5 255 8,5 255 7,5 225 9 200 10,6 200 11 180 11 180 10,8 180 11,2 160 12,9 160 13 140 13 100 14,5 100 14,5 100 14,5 100 14,5 60 22 Number of Adapters: 24 pcs Size Quantity 480 8 590 8 710 8 Number of sleeves approx: 400 (400/410/420...up to 900mm Outside size approx 8 per set) Doctor blade chambers: 14 pcs Earliest Pick up: Second week of October 2026 Latest date of removal: End of December 2026
