Gebrauchte SCREEN PT-R FX1524N Jahr 2013 zum Verkauf

Technische Details:

• Beschreibung: CTP Recorder

Weitere Spezifikationen:

Product Name: PlateRite FX1524N
Media: Letterpress digital plates, flexo digital plates, dry films, thermal offset plates (option)
Media sizes*1: Maximum 1,524 × 1,067 mm (60.0" × 42.1") Minimum 200 × 100 mm (7.9" × 4.0")
Media thickness*1: 0.10 to 6.35 mm
Resolution: 2,400 dpi, 2,540 dpi, 4,800 dpi*2
Productivity: 4 to 6 m2/h (6,200 to 9,300 sq in/h)*3
Options: Upgrade to FX1524N, thermal offset plate option*4, inline UV LED exposure function

Dimensions (W × H × D):
Main unit: 2,450 × 1,210 × 1,110 mm (96.5" × 47.7" × 43.8")*7
Air filtering unit: 530 × 840 × 670 mm (20.9" × 33.1" × 26.4")
Blower unit: 685 × 550 × 670 mm (27.0" × 21.7" × 26.4")
Chiller unit: 350 × 715 × 660 mm (13.8" × 28.2" × 26.0") (UV LED option)

Weight:
Main unit: 1,120 kg (2,464 lb)
Air filtering unit: 90 kg (198 lb)
Blower unit: 50 kg (110 lb)
Chiller unit: 63 kg (138.6 lb) (UV LED option)

Power requirements:
Main unit: Single phase 200 to 240 V, 20 A, 4 kW
Air filtering unit: Single phase 200 to 240 V, 16 A, 3.2 kW
Blower unit: Single phase 200 to 240 V, 10 A, 1.2 kW
Chiller unit: Single phase 200 to 240 V, 3 A, 0.6 kW (UV LED option)

Environment: Temperature: 21 to 25°C (69.8 to 77°F) [recommended], Relative humidity: 40 to 70% (no condensation)

*1 Limitations may exist depending on the plate material. *2 Note that 4,800 dpi screening is not possible for thermal offset plates. *3 Productivity may vary depending on the media sensitivity.
*4 Supported thermal offset plate sizes range from a maximum of 1,165 × 950 mm (45.9" × 37.5") to a minimum of 320 × 100 mm (12.6" × 4.0").
*5 Supported thermal offset plate sizes range from a maximum of 870 × 762 mm (34.3" × 30.0") to a minimum of 200 × 100 mm (7.9" × 4.0"). *6 This is available as a factory option. It is for steel based plates.
*7 The depth of systems equipped with UV LEDs is 170 mm longer than the standard specifications. *8 The depth of systems equipped with UV LEDs is 135 mm longer than the standard specifications.

Weitere Angaben:

Garantie: Ohne Garantie

Operativität: In Betrieb

Verfügbarkeit: Sofortige
