Technical Specifications:
Clamping Force: 160 ton
Shot Weight (Max): 278 g
Distance Between Tie-Bars (H): 520 mm
Distance Between Tie-Bars (V): 520 mm
Platen Size (H): 820 mm
Platen Size (V): 845 mm
Screw Diameter: 45 mm
Mould Height (Min): 300 mm
Daylight Between Platens (Max): 950 mm
Opening Stroke (Max): 650 mm
Ejector Force: 2.3 ton
Ejector Stroke: 150 mm
Screw L/D Ratio: 22
Screw Speed: 265 rpm
Injection Volume: 318 cm³
Injection Pressure: 2336 bar
Injection Rate: 143 cm³/s
Plasticising Capacity: 29 g/s
Heating Zones: 5
Heating Capacity: 15.62 kW
Other Specifications:
Working hours – 82 000
Motor – 18,5 kW
Other Details:
Guarantee: Without guarantee
Current condition: In Production
Availability: > 3 months
Voltage: 380 V Triphase
Frequency: 50 Hz
