Used KRONES Variopac of 2018 for sale

2018 | Ref.: 300042278

Shrink wrapper for cans KRONES, The team at MachinePoint will accompany you through the whole process of buying the machine.


Data Sheet of Used KRONES Variopac

Ref.: 300042278

Year: 2018

Brand: KRONES

Status:
For sale

Delivery time: Immediate


Ask for machine price Want to sell your machine?

Technical Specifications:


  • Output: 7200 U/h
  • Format: 330ml Standard & Sleek

Other Specifications:



Krones Variopac shrink-packer with pad, year 2018

Speed: 120 packs/min, up to 3 lanes
Infeed: 10 lanes
Foil : transparent & printed shrink film

Cans : 33cl standard – 33cl sleek possible
Minimum rated Line speed by size:
150ml: 120,000 cph
250ml: 120,000 cph
330ml: 120,000 cph
500ml: 94,000 cph
3 Validated formats :
· X6 (3x2) 33STD 3 lanes
· X9 (3x3) 33STD 2 lanes
· X18 (6x3) 33STD 1 lane
Formats in but not developed in production
· X15 (5x3) 33STD 2 lanes
· X12 (5x3) 33STD 2 lanes
Foils real : 2 places – automatic change without stop
PAD magazine : 1 & 2 lanes
Change over : semi & automatic change over with HMI description + automatic check of parts
Gas Oven : longer one in Krones variopac range

In production until the end of January 2021

Available immediately!

Other Details:


Guarantee: Without guarantee

Current condition: In Production

Availability: Immediate

Clasification:


Final Products: Carbonated Soft Drinks (CSD)

Used Materials: Cans

Processes: Packing
