Technical Specifications:
Clamping Force: 210 ton
Shot Weight (Max): 158 g
Distance Between Tie-Bars (H): 580 mm
Distance Between Tie-Bars (V): 580 mm
Platen Size (H): 880 mm
Platen Size (V): 850 mm
Screw Diameter: 35 mm
Mould Height (Min): 340 mm
Daylight Between Platens (Max): 1265 mm
Opening Stroke (Max): 575 mm
Ejector Force: 6 ton
Ejector Stroke: 165 mm
Screw L/D Ratio: 20
Injection Volume: 170 cm³
Injection Pressure: 2800 bar
Nozzle Force (Max): 3 ton
Nozzle Stroke (Max): 350 mm
Heating Capacity: 9,40 kW
Other Specifications:
Worked hours 26673 hours (May 2023)
Hours under power 32725 hours (May 2023)
Injection and Clamp Drives renewed in 2015
The machine is in good condition.
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 400 V Triphase
Frequency: 50 Hz
Full Electric
