Technical Specifications:
Clamping Force: 250 ton
Shot Weight (Max): 607 g
Distance Between Tie-Bars (H): 630 mm
Distance Between Tie-Bars (V): 630 mm
Platen Size (H): 900 mm
Platen Size (V): 900 mm
Screw Diameter: 60 mm
Control Type:Electronic
Mould Thickness (Min): 300 mm
Daylight Between Platens (Max): 1300 mm
Opening Stroke (Max): 600 mm
Ejector Force: 8.76955943161018 ton
Ejector Stroke: 225 mm
Type Of Clamp:Hydraulic
Core Pulls:Yes
Number Of Core Pulls: 3
Dry Cycle (S): 2.3 s
· INJECTION UNIT: 1300
Screw L/D Ratio: 20
Injection Volume: 664 cm³
Injection Pressure: 2000 bar
Injection Rate: 284 cm³/s
Nozzle Force (Max): 9.17744591680136 ton
Nozzle Stroke (Max): 550 mm
Heating Zones: 6
Heating Capacity: 22 kW
Oil Tank Capacity: 390 l
Other Specifications:
Working hours: 65.000 h
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 400 V Triphase
Frequency: 50 Hz
Voltage: 70.5 Kw
