Used AMUTEC TSA-MP-A 640 of 2016 for sale

2016 | Ref.: 300042755

Bottom weld bags on the roll AMUTEC, MachinePoint chooses the best machinery on sale in the market and we offer our clients a selection of high quality machinery.


Data Sheet of Used AMUTEC TSA-MP-A 640

Ref.: 300042755

Year: 2016

Brand: AMUTEC

Status:
For sale

Delivery time: Immediate


Ask for machine price Want to sell your machine?
Please accept marketing-cookies to watch this video.

Technical Specifications:


  • Welding Width: 1600 mm
  • Bag Length (Max): 20000 mm
  • Bag Length (Min): 100 mm
  • Cycles Per Minute: 300 U/min
  • Drive: Servo
  • Number Of Lanes: 4

Other Specifications:


Welding machine working from reel to reel for the production of welded and pre-cut bags starting from a large format tubular reel, divided into various lanes to be then rewinded on cardboard or plastic cores.
Hydraulic lifting and peripheral unwinding device 1660 m for reels with diameter up to 1200 mm, shaft-less type for cores with internal diameter 76 mm.
Automatic FIFE centering unit
Cutting/welding unit with 3 heads
Gusseting device 1700 mm for the production of up to 4 tracks
Accessory with 4 lanes for "Star-Bags" round bottom bags complete with single folding triangles and inversion bars
Automatic rewinder with two stations with non-stop changeover and automatic unloading
FiFE before the winder
Core feeding hopper

Thicknesses 2x6my- 2x50my
Max final roll diameter 240mm

Other Details:


Rebuild: 8,+9

Guarantee: Without guarantee

Current condition: In Production

Availability: Immediate

Voltage: 400 V Triphase
Frequency: 50 Hz
Voltage: 12 Kw
