Technical Specifications:
Clamping Force: 190 ton
Shot Weight (Max): 525 g
Distance Between Tie-Bars (H): 460 mm
Distance Between Tie-Bars (V): 460 mm
Screw Diameter: 55 mm
Mould Thickness (Max): 550 mm
Mould Thickness (Min): 200 mm
Ejector Force: 5 ton
Ejector Stroke: 150 mm
Dry Cycle (S): 35 s
Screw L/D Ratio: 20
Screw Speed: 440 rpm
Screw Torque: 2100 N·m
Injection Volume: 546 cm³
Injection Pressure: 1450 bar
Injection Rate: 280 cm³/s
Plasticising Capacity: 160 g/s
Heating Zones: 3
Heating Capacity: 13,80 kW
Oil Tank Capacity: 315 l
Orientation:Horizontal
Other Specifications:
2 identical machines available
Price per unit.
Machines fully overhauled in 2010
Other Details:
Rebuild: 2010
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 43 Kw
