Used ENGEL e-max 200/100 of 2008 for sale

Injection molding machine up to 250 T ENGEL, We will be by your side all along the process of buying your machinery, from the initial assessment, accompanying you in the visits, legal and technical consultancy, and defined contracts that will protect you.

Data Sheet of Used ENGEL e-max 200/100

Ref. : 300043752

Year: 2008

Brand: ENGEL

Status: For sale

Delivery time: Immediate

Technical Specifications:

Clamping Force: 100 ton

Shot Weight (Max): 77 g

Distance Between Tie-Bars (H): 450 mm

Distance Between Tie-Bars (V): 410 mm

Platen Size (H): 650 mm

Platen Size (V): 600 mm

Screw Diameter: 30 mm

Mould Height (Max): 450 mm

Mould Height (Min): 150 mm

Opening Stroke (Max): 350 mm

Ejector Force: 2.4 ton

Ejector Stroke: 100 mm

Dry Cycle (S): 1.45 s

Screw L/D Ratio: 20.5

Screw Speed: 400 rpm

Injection Volume: 85 cm³

Injection Rate: 157 cm³/s

Nozzle Stroke (Max): 220 mm

Heating Zones: 4

Other Specifications:

The PLC driver must be replaced

Other Details:

Guarantee: Without guarantee

Current condition: Disconnected. Can't be seen in running condition

Availability: Immediate

Full Electric
