Used LIANSU Ø  200-630 mm of 2020 for sale

2-layer extrusion line for HDPE pipes with four colour stripes in the diameter range 20-110 mm Capacity: 200 kg/h Max speed 10 m/min Extruders: Main extruder Liansu LSS 65/35 ; output up to 350 kg/h; year 2018 Siemens AC Main motor; ABB inverter; Taiwan gearbox Co extruder Liansu LSS 45/30; output up to 40 kg/h; year 2018 Siemens AC Main motor; ABB inverter; Taiwan gearbox Stripes: extruder Shang Hai Jinhu; year 2006 Die head: for dimension of 20-110 mm (with all tools) Vacuum tank: Periplast; 6 m; year 2001 Water tank: Liansu; 6 m; year 2022 Haul off: Liansu: ISPQ 110, year 2013 Vacuum loaders: Shini SAL 800G2: year 2016 Available: August 2024

Complete line for PVC pipes 200-500 mm 1. Extruder Manufacturer: Liansu Type: LSE92/188 Year: 2011 (screws and barrel revisioned in 2015) Heating/cooling zone 6/5 Screw rotating speed (r/min)40.5 Main motor (kW) 110 Total power (kW) 172 Output (kg/h) 800÷850 2. Vacuum-cooling bath Type: no data Year: no data 3. Cooling bath Type: WCH 200-630 Year: 1995 4. Haul-off Manufacturer: SICA Type: C500 Year: 1993 5. Saw Manufacturer: SICA Type: TRS 100-500 Year: 1993 6. Belling machine Manufacturer: SICA Type: BA.CA.1T.H 100-500 Year: 1994 Working hours of extruder can´t be established (lack of counter) Die head is not a part of the offer Machine SICA tipo BA.CA.1T 110-500, year 1994. Tools are not part of the offer. CAN BE BOUGHT SEPARATELY

Extrusion line Liansu LSAP-63PPR for the production of single-layer pipes. Capacity: of 300 kg / hour Range of diameters: from 20 to 63 mm Installed power: 240 kW Max. water consumption: 20 cubic meters per hour Air pressure: 0,6 ... 0,8 MPa Water pressure: 0,2 ... 04 MPa Dimensions: 53000 * 1400 * 2650 mm It includes: - single-screw extruder LSS65-34 - extrusion head (originally for pipe inner-layer) - vacuum tank LSAP 63 - irrigation tank LSP 63 - heating chamber - vacuum pump - haul off unit LSAP 63 - the cutting unit LSAP 63 - pipe end trimming unit The line was originally designed to produce pipes reinforced with aluminium tape using adhesive technology. All equipment for this technology is included in the offer: LSS40-25 (adhesive), LSS30-25 (stripe), extruder LSS50-34 (outer layer), aluminum pipe shaper, fan, extrusion head for outside tubes, an unwinding device.

Swarfless pipe cutter Max wall thickness SDR11

Swarfless pipe cutter Max wall thickness SDR11
