Technical Specifications:
Clamping Force: 180 ton
Shot Weight (Max): 202 g
Distance Between Tie-Bars (H): 520 mm
Distance Between Tie-Bars (V): 520 mm
Platen Size (H): 760 mm
Platen Size (V): 775 mm
Screw Diameter: 40 mm
Mould Height (Max): 250 mm
Mould Height (Min): 600 mm
Opening Stroke (Max): 460 mm
Ejector Force: 3.77294998801833 ton
Ejector Stroke: 130 mm
Dry Cycle (S): 1.8 s
Screw L/D Ratio: 20
Screw Speed: 420 rpm
Injection Volume: 220 cm³
Injection Pressure: 1950 bar
Nozzle Force (Max): 2.8552053963382 ton
Nozzle Stroke (Max): 305 mm
Plasticising Capacity: 33.6 g/s
Heating Zones: 4
Other Specifications:
2 units available, price for unit.
Other Details:
Guarantee: Without guarantee
Current condition: Not running. Can be shown in dry cycle
Availability: Immediate
Voltage: 380 V Triphase
Frequency: 60 Hz
