Used ENGEL VC 200/80 of 2008 for sale
2008 | Ref.: 300045898
Injection molding machine up to 250 T ENGEL, The team at MachinePoint will accompany you through the whole process of buying the machine.
Data Sheet of Used ENGEL VC 200/80
Ref.: 300045898
Year: 2008
Brand: ENGEL
Status:
For sale
Delivery time: Immediate
Ask for machine price Want to sell your machine?
Technical Specifications:
- Clamping Force: 80 ton
- Platen Size (H): 670 mm
- Platen Size (V): 600 mm
- Screw Diameter: 25 mm
- Mould Height (Min): 200 mm
- Daylight Between Platens (Max): 650 mm
- Opening Stroke (Max): 450 mm
- Ejector Force: 4 ton
- Ejector Stroke: 100 mm
- Dry Cycle (S): 1.5 s
- Screw Speed: 480 rpm
- Injection Volume: 69 cm³
- Injection Pressure: 2090 bar
- Injection Rate: 104 cm³/s
- Nozzle Force (Max): 2.8 ton
- Nozzle Stroke (Max): 200 mm
Other Details:
Guarantee: Without guarantee
Current condition: In Production
Availability: Immediate
