Used THERMOWARE THW 3500 of 1993 for sale

Pack of 3 EPS cups machines including testing & counting machine & pre-expander VA40 (year 1999) 1/EPS cups machine THW 3510 YEAR 2002 Max number of moulds : 10 Drawing : Illustration 2-2 Weight : 1900kg Dimensions Lxlxh : 2070x1780x2200 Steam : Pressure bar : min 7 Consumption kg/h : 300-350 Connection : 1.5" Cooling water : Pressure bar : min 4-4.5 Temperature : 35-40C Consumption : 2-2.5 m3/h Connection : 1.5" Air : Connection : 1" Pressure bar : min 7 Consumption m3/min : 0.8-1.0 Consumption take-out unit (m3/min) : 0.3 Electricity : Supply : 220 VAC 1ph+N+FG Rated power : 0.3kW 400V/50Hz 2/EPS cups machine THW 3516 YEAR 2005 Max number of moulds : 16 Drawing : Illustration 2-1 Weight : 1950kg Dimensions Lxlxh : 2070x1780x2450 Steam : Pressure bar : min 7 Consumption kg/h : 400-450 Connection : 1.5" Cooling water : Pressure bar : min 4-4.5 Temperature : 35-40C Consumption : 3-3.5 m3/h Connection : 1.5" Air : Connection : 1" Pressure bar : min 7 Consumption m3/min : 1-1.5 Consumption take-out unit (m3/min) : 0.3 Electricity : Supply : 110-230 VAC 1ph+N+FG Rated power : 0.3kW 400V/50Hz 3/EPS cups machine THW 3508 YEAR 1999 Max number of moulds : 8 Drawing : Illustration 2-1 Weight : 1750kg Dimensions Lxlxh : 2070x1480x2200 Steam : Pressure bar : min 7 Consumption kg/h : 300-350 Connection : 1.5" adaptor 1" Cooling water : Pressure bar : min 4-4.5 Temperature : 35-40C Consumption : 2-2.5 m3/h Connection : 1" Air : Connection : 1" Pressure bar : min 7 Consumption m3/min : 0.8-1.0 Consumption take-out unit (m3/min) : 0.3 Electricity : Supply : 220 VAC 1ph+N+FG Rated power : 0.3kW 400V/50Hz

Pack of 4 EPS foam cup machines, molds, 2 packaging units, 2 tester units (1 tester THW 125E year 2005 & 1 tester THW 3320 year 2008), 1 pre-expander THW VA 40 year 2005 & 4 Silos Reason for selling: Change of production field. Working hrs: 50.000 to 60.000 hrs/machine New condition 2 EPS machines THW 3516 year 2008 Max number of moulds : 16 OF 12OZ Drawing : Illustration 2-1 Weight : 1950kg Dimensions Lxlxh : 2070x1780x2450 Steam : Pressure bar : min 7 Consumption kg/h : 400-450 Connection : 1.5" Cooling water : Pressure bar : min 4-4.5 Temperature : 35-40C Consumption : 3-3.5 m3/h Connection : 1.5" Air : Connection : 1" Pressure bar : min 7 Consumption m3/min : 1-1.5 Consumption take-out unit (m3/min) : 0.3 Electricity : Supply : 110-230 VAC 1ph+N+FG Rated power : 0.3kW 400V/50Hz 2 EPS machines THW 3510 year 2005 Max number of moulds : 10 OF 8 OZ AND 16OZ Drawing : Illustration 2-1 Weight : 1750kg Dimensions Lxlxh : 2070x1480x2200 Steam : Pressure bar : min 7 Consumption kg/h : 300-350 Connection : 1.5" adaptor 1" Cooling water : Pressure bar : min 4-4.5 Temperature : 35-40C Consumption : 2-2.5 m3/h Connection : 1" Air : Connection : 1" Pressure bar : min 7 Consumption m3/min : 0.8-1.0 Consumption take-out unit (m3/min) : 0.3 Electricity : Supply : 220 VAC 1ph+N+FG Rated power : 0.3kW 400V/50Hz MOLDS INCLUDED : 8OZ 10 MOLDS 12OZ 58 MOLDS 16OZ 10 MOLDS

Thermoforming area: 1200x1300 Max moulding positions: 95mm Material: EPS dimensions of 80 ml cup: 55,6 mm high; 57 mm diameter diemnsions of 200 ml cup: 92,3 mm high; 79,4 mm diameter Automatic Horizontal moulding machines for cups, food trays, containers and packaging Automatic Hopper loading system Pressure fill system PLC control cabinet with digital front panel Mould champing by toggle lever system Reed contact limit switches Steam pressure min 7 bar Air consuption 0,8-1 m3/min Water cooling consumption: 2-2,5 m3/h Steam consuption: 300-350 kg/h The machines have been working for 5 years and have not been in production in the last 10 years, Also available a horizontal packer Micropack VRP year 2001 and EPS preexpander ThermowareTHW VA80E year 2000

EPS Shape Moulding machine: No. 2 machines THERMOWARE THW3510 complete one of them never used, still in its original packing > 1 x pre-expander VA80 > 1 x hopper loader 80HL > 1 x dryer FB80 > 1 x sieve DTS80 > 2 x silo 8m3 (incl. frame) > 1 x material transport system for 2 silo's > 1 x material divider MDV 1704 > 2 x production machine 3510 > 5 x 6oz molds > 5 x 8oz molds

Production of EPS cups, bowls and lids Consisting of: Moulding Machine THW 3510 D, 10 cavity Cup molds 4 Oz (10 pieces) (POR Price on Request) Container molds 16 oz (10 pieces) (POR Price on Request) Capacity 2500-3500 parts/hour
