Used TECNOVA of 2006 for sale

Regeneration plant with water head cutting for PE/PP/PS 8mm diameter screen Print max. 50% - humidity max. 3 Film silo, capacity 2mc Forced feeding Extruder 60 LD 35 with degassing Vacuum pump for degassing DC motorization Temperature control panel Manual screen changer Pressure control Water head cutter Big bag holder Venturi, cyclone and tubes

REGRANULATION LINE WITH WATER CUTTING AT THE HEAD INPUT MATERIAL LDPE FILM, CLEAN AND DRY Printing percentage up to 50%, material humidity up to 3% SILOS 13 M3 made of carbon steel with forced material flow controlled by a 3HP motor,with Plexiglass material level control windows, loading cyclone with filters and dust sleeve FORCED FEEDING feeding hopper adapted to the extruder connection, screw pressure screw controlled by a gear motor with a 12.5 HP motor with an inverter EXTRUDER WITH DEGASSING frame made of welded steel, reducer without clutch, reinforced gears, hardened VACUUM DEGASSING PUMP 10 HP ring pump fitted with a tank for the monomer smasher AC MOTOR WITH INVERTER 280 HP AC motor, 400V 50Hz, with console and control panel with three-phase inverter maximum 280 HP TEMPERATURE CONTROL SCREEN WITH HEAT EXCHANGER with 6 electronic thermoregulators with double protection for the cylinder and 6 thermoregulators with single protection for filter changer and head - dust filters IP 45 HYDRAULIC SCREEN CHANGER BD PLAST filtration zone with a diameter of 220 mm This screen changer is the original one and has been working only one year. Now it is not installed but it will be installed before the delivery HYDRAULIC CONTROL UNIT to control the piston of the changer, accumulator with a capacity of 20l, pump controlled by a motor 7.5HP, oil tank capacity 120 l, max pressure 200 atm. PRESSURE CONTROL SCREEN fluid pressure control with diaphragm probe, dual protection levels - first audible signal - second extruder stop. WATERJET CUTTING ON 90°C HEAD VIBRATING SCREEN flat screen with two entrances made of welded steel, separating granules with holes with a diameter of 8mm, controlled by a 0.5HP motor dimensions 1400X500X900H Available automatic filter Cofit GB1000L (installed), price on request. Average power consumption: 250kW COOLING WATER DEMAND: 2200L/H

Recycling line for Pe composed by Conveyor belt Grinder Silos for grinded material Extruder with forced feeding system and degassing Silo for pelets and system to put them in big bags

Complete line including: Feeding silo for shreded film of 12 m3 Forced feeding system, placed to be conected to the extruder. Motor 13,5 HP Extruder equiped with degassing CC Motor of 181 Kw 6 Heating zones of 220 Kw Vacum pump for degassing. Motor drive 7,5 HP Temperature controling panel Hydraulic filter changing system, diam. 220 mm Pressure control system Water cooled cutting system on the die head with 4 blades. Motor drive 4 Kw Inox swinging water bath for granules and separation sieve Mechanical centrifuging unit built in Inox. Centrifugal fan for granules. Motor of 4 Kw Storing silo for pelletes approx. 1000 Kg

Regeneration plant with water die-face cutting for PP/PS grinded by screen diam. 8 mm printed max. 50% - humidity max. 3%. Suitable for recycling of LDPE - HDPE - PP sheet. Output 120/150 Kg/h. Total installed power: kW 90 Average power used: kW 55 Cooling water consumption: l/h 800 Current production: 150kg/h plastic cup recycling process. Working hours : 450h Included : Instruction manual, screens and new spare parts. The line consists of : *SILO FOR FILM, CAPACITY: mc 2 internal movement controlled by a 2 HP motor reducer. - min/max levels both visual with plexiglass panels and electric with alarm lamp - door for control and cleaning - cyclone for material inlet equipped with bag filters for air decantation. *FORCED FEEDING hopper for forced feeding provided for fixing to the extruder - pressure screw controlled by 1 HP gear motor. - easily interchangeable LK3 feeding section There is an opening on the hopper (see photo), but it is possible to install an additional feed. *EXTRUDER 60 LD 35 WITH DEGASIFICATION welded steel structure - gearbox without gear change with case-hardened, hardened and ground gears contained in spheroidal graphite cast iron - reduction ratio 1/10 - oil-bath lubrication with pump and heat exchanger for internal cooling - barrel and screws in nitriding steel, improved to 100 kg. and nitrided at 1050 HVC - degassing with lateral chimney provided for the application of the monomer removal device connected to the vacuum pump - cast iron casting feed zone with built-in water circulation cooling chamber, easily controllable from the outside for cleaning without having to dismantle it and provided with nitrided internal jacket with longitudinal grooves easily interchangeable - foreseen for the application of the forced hopper - 6 barrel temperature control zones connected by thermocouples to the general control panel - each zone is cooled by 1 centrifugal fan - heating ceramic resistors. *VACUUM PUMP FOR DEGASSING 2 HP liquid ring pump. - provided with container for monomer extraction device - manometer for vacuum control and connection pipes to the degassing chimney. *D.C. MOTORIZATION 100 HP direct current motor. equipped with tachometric dynamo for screw/motor rotation control - 1:10 constant torque 1:10 motor speed control feeder - armature voltage 440 V - excitation 110/ 220 V - 380 V 50 Hz line - equipped with control and command board with built-in three-phase feeder for maximum power 100 HP. - general disconnector and all accessories. * TEMPERATURE CONTROL PANEL with 6 double intervention electronic thermoregulators for the thermowell and 5 single intervention for the control of the screen changer and head - IP 45 dustproof execution - daily/weekly clock and display for self-diagnostic routine. * MANUAL SCREEN CHANGER filtering section diam. 90 mm- - body in forged sink - sliding plate in hardened and ground steel. *PRESSURE CONTROL pressure control of the fluid mass with membrane probe - double alarm thresholds: the first one for signalling, the second one for safety shutdown of the extruder - acoustic/visual alarm signalling device placed on the main panel. *WATER HEAD CUTTING neck for connection to the screen changer - vertical axis extrusion head with interchangeable die - circular stainless steel cooling chamber - blade-holder star driven by 3 HP AC motor with cutting pressure adjustment - tilting water / pellet conveyor and screen for separating them made of stainless steel water collection tank with 2 HP centrifugal pump. - mechanical centrifuge with vertical axis driven by 3 HP motor. with compartment basket and control doors for cleaning built in stainless steel steam extraction fan placed on the upper part of the centrifuge - control and command panel equipped with thermoregulator. *BIG BAG SUPPORT *VENTURI, CYCLONE AND TUBES
