Used Sorting and separating plants

Tomra INNOSORT is a reliable sorting technology based on material (polymer) and color sorting of plastic flake (PE,PP, PET etc.) impurities NIR detection system Through CRGB system (double-side camera), other color impurities (transparent and opaque) will be removable Flakes: recommended size 2-12 mm Working width: 1000 mm (2 chutes system) Including metal stand Working hours: machine run time 135 h; sorting time 40 h

OMRON SENTECH COLOUR SCAN SYSTEM MACHINE Model LS 001 Year 2021 Output capacity 200-230VAC

The Schlitz-O-Mat Bag opener opens the plastic sacks and transfers the metered material to the subsequent sorting and preparations plants. Schlitz-O-Mat XXL 2-21 -26: Drum diameter: 1000mm Throughput capacity: 10.000 kg/h at 50 kg/m3 Drive: electro-hydraulic Drive power: 22kW Max. pressure: 300 bar Tank capacity: 160 Liter Feed hopper with moving floor discharge: Conveying speed: max. 1.5m/min, infinitely variable Bunker volume: approx. 14 m3 Drive: electro-hydraulic Drive power: 5,5 kW Max. pressure : 200 bar Tank capacity : 90 Liter

Product: PET Trays Size: 50 – 350 [mm] Capacity: up to 2,500 kg/h Product speed: 2,5 m/s Product temperature / moisture content +5 to +40 / < 10 [°C/%] Temperature: +5 to +40 [°C] Working width: 1,920 mm Equipment Specifications: High speed conveyor belt Air storage tank and control unit Housing: mild steel, RAL 9007 painted, covers green painted Metal Detection: Multi-channel-metal detection coil Linear resolution 16 mm Sensitivity: Ferrous ball 1,0 mm Aliminium ball 1,5 mm Polymer Detection: NIR Sensor Resolution 8 mm Rejection system: By means of high speed solenoids Directly mounted for short activation times Valve number (Top and Bottom) 240 Control unit: Industrial PC with touchscreen equipped with: audible and visible alarm display adjustable sensitivity adjustable time delay adjustable rejection time free programmable programs Optimum Operating Conditions: Fed by means of a vibratory feeder Even distribution of the input material Material evenly thinned out VISUTEC Visualization- and Control System including Remote Control All separators can be networked with a PC on which the Visutec data management software is installed. The Visutec software provides an optimal quality control center. Control of process related key figures of: Input materials Final product Input amount Output amount

Channels 6 Ejectors 378 Ilumination LED Resolution CCD camera (pixels) 5000x3 Output 2 .2 Tn/h Sorting accuracy >99% Optimal sorting accuracy ratio > 20:1 (depending on material) Air pressure ≥ 6 Mpa Air consumption 900 - 3.000 l/min
